| PPG-125-1 | PPG-125-1-C | PPG-125-1-O | |
| Type | Common two-finger pneumatic gripper with width of 125mm | Normally closed Two-finger pneumatic gripper with width of 125mm | Normally open Two-finger pneumatic gripper with width of 125mm |
| Stroke per Finger (mm) | 13 | 13 | 13 |
| Closing Force (N) | 1400 | 2000 | / |
| Opening Force (N) | 1520 | / | 2120 |
| Weight (kg) | 1.4 | 1.9 | 1.9 |
| Recommended Workpiece Weight (kg) | 7 | 7 | 7 |
| Fluid Consumption per Double Stroke (cm3) | 110 | 160 | 185 |
| Minimum Operating Pressure (bar) | 2.5 | 4 | 4 |
| Maximum Operating Pressure (bar) | 8 | 6.5 | 6.5 |
| Rated Operating Pressure (bar) | 6 | 6 | 6 |
| Closing Time (s) | 0.09 | 0.08 | 0.12 |
| Opening Time (s) | 0.09 | 0.12 | 0.08 |
| Maximum Allowable Finger Length (mm) | 180 | 170 | 170 |
| Repeatability(mm) | 0.01 | 0.01 | 0.01 |
